Transform rigid-substrate printing with XENONS DREAMS One Pass industrial inkjet technology. Designed for production environments that demand throughput, repeatability, digital customization,
and efficient material handling, DREAMS systems combine fixed printhead arrays, UV inkjet printing, and configurable automation into an integrated manufacturing solution.
From packaging and retail displays to decorative panels and selected industrial applications, DREAMS helps manufacturers build a more responsive digital production workflow.
 |
 |
| XENONS DREAMS 1224 UV ONEPASS FLATBED PRINTING SOLUTION (1240) |
What Is One Pass Industrial Printing? |
Fully Automatic Ultra-High-Speed UV Inkjet One-pass Board Printing Production Line | ||
|
Supports direct printing on a wide range of rigid substrates.
Global decorative building. panel market is growing steadily, driven mainly by commercial renovation & retail fit-out projects.
The shift from pre-finished decorative boards to digitally printed plain substrates creates huge opportunities for industrial UV inkjet. OnePass flatbed printers address the pain point of low throughput of conventional multi-pass UV machines, enabling mass customization for PVC, MDF, HPL, PET panels, ACP, sintered stone and display materials.
|
One Pass printing is a digital inkjet printing method in which a fixed printhead array spans the required printing width while the substrate moves through the printing zone. The image is produced as the material passes the printheads, rather than requiring a conventional scanning carriage to traverse the same area repeatedly. This architecture can reduce repetitive printhead movement and support high-throughput production. When integrated with appropriate feeding, curing, inspection, and handling systems, One Pass printing can become part of a more automated industrial workflow. Actual throughput and print quality depend on printhead configuration, ink coverage, resolution, substrate characteristics, curing requirements, and production-line design. |
Supports direct printing on a wide range of rigid substrates.
Global decorative building panel market is growing steadily, driven mainly by commercial renovation & retail fit-out projects.
The shift from pre-finished decorative boards to digitally printed plain substrates creates huge opportunities for industrial UV inkjet. OnePass industry printers address the pain point of low throughput of conventional multi-pass UV machines, enabling mass customization for PVC, MDF, HPL, PET panels, ACP, sintered stone and display materials. |
 |
 |
 |
| Sharp tiny text & scannable micro QR codes, variable data support |
Print gloss & matte on same substrate in one pass |
Pre-reserved 6-color channel for white ink / spot color / varnish upgrade |
 |
 |
 |
| Double-sided printing with 0.2mm accurate registration |
Non-contact printhead cleaning to extend head service lif |
30% higher precision, 40% less UV ink consumption |
| Dimension | Scanning UV Printing | Dreams One-pass UV printing |
| Architecture | Scanning | ONE Pass & Scanning |
| Printhead arrangement | Limited (few printheads) | Page-wide (full-width) |
| Four color Printhead wide | 53mm-720mm | 1250mm-1680mm |
| Production method | Batch | Continuous |
| Automation | Not achievable | Fully automatic |
| Production management software | None | Order system + Production Management System + IoT |
| Labor | Multiple operators | Reduced (fewer operators) |
| Machine utilization | Always very low | Very high with stable orders |
| Floor space | High (large footprint) | Lower (smaller footprint) |
| Color consistency | Machine-to-machine variation | Unified |
| High-volume orders | Limited | Designed for mass production |
| Return on Investment (ROI) | Low (low for small orders; also low when large orders cannot be produced) | High (higher ROI with larger orders) |
| About Drops Printheads Calibration & Print Alignment Ink Technology Color Management |
Advanced Printhead + ink+ color Integration Industrial Quality Reliability & buying QA |
| Item | Parameter | ||
|---|---|---|---|
| Printheads | |||
| Type | T3200U3-2 | G6 | KM9888H |
| Arrangement | 19×2 / 19×3 | 24×2 / 24×3 | 19×2 / 19×3 |
| Quantity | 38 / 57 pcs | 48 pcs | 38 pcs |
| Print Speed | |||
| Printing Solution | UV / GUV | UV / GUV | UV / GUV |
| High-efficiency Mode | 4pass: 11 s/pcs | 4pass: 9 s/pcs | 4pass: 9 s/pcs |
| Production Mode | 6pass: 17 s/pcs | 6pass: 13 s/pcs | 6pass: 13 s/pcs |
| Quality Mode | 8pass: 23 s/pcs 12pass: 45 s/pcs | — | — |
| Ink Supply System | |||
| Ink Type | UV Ink | ||
| Ink Color | CMYK / WCMYKV / CMYKLcLm / CMYKOrGr | ||
| Ink Tank Volume | 15 L per color | ||
| Ink Supply Method | Two-stage constant temperature & negative pressure | ||
| Printing Substrates | |||
| Max. Printing Width | 1224 mm | ||
| Substrates | PVC, KT board, Coated Art Paper | ||
| Substrate Thickness | 0.3 mm – 50 mm | ||
| Software System | |||
| RIP Software | FEIRY (Former EFI) | ||
| Production Software | Yilios | ||
| Image Format | PDF, TIFF, JPG | ||
| IoT System | yiliOS4 | ||
| Functional Configuration | |||
| Printing Platform | Vacuum suction table | ||
| Drive System | Substrate: 3 rails + high-speed linear motor Carriage: 10 rails + high-speed linear motor | ||
| Loading & Unloading System | Manual + auto lifting platform; Optional single-gantry automatic loading & unloading | ||
| Conveying System | Linear motor | ||
| Lifting Function | 4-screw 4-axis with heavy-duty gantry lifting structure | ||
| Auto Cleaning & Humidifying Assembly | Non-contact negative-pressure cleaning (suction nozzle type), servo motor with dual linear guide drive | ||
| Working Environment | |||
| Power Supply | Dual power: 380V / 220V | ||
| Power Consumption | Peak: 22 kW Operating: 12 kW | ||
| Air Pressure | 2.2 MPa | ||
| Temperature & Humidity | 20–30 ℃, 55–75% RH | ||
| Dimension & Weight | |||
| Machine Dimension | 7000 mm × 2400 mm × 2600 mm | ||
| Packing Dimension | 7000 mm × 2400 mm × 2600 mm ×1.12 | ||
| Machine Weight | 6250 Kg | ||
| Packed Weight | 7250 Kg |
| Selling Point Name | Selling Point Description |
|---|---|
| Fast Printing Speed | 4pass: 11s/pcs；6pass:17s/pcs；8pass:23s/pcs |
| High Printing Precision | Adopts monochrome 600dpi printing mode. High-precision carriage with adjustable error of 0.02mm. Supports 4–12pass printing. Available with image mode & solid color mode to meet diverse requirements. |
| Superior Performance for Fine Text & Barcodes | High sharpness for tiny texts. Supports ultra-small QR code printing for instant scanning. Variable data printing function available. |
| Gloss & Matte Finish Available | Supports full gloss printing solution and full matte printing solution. |
| Proprietary One-Pass Gloss & Matte Printing | Exclusive technology to print gloss and matte effects on the same substrate in one single pass. Two finishes in one print expands application scenarios without extra investment in machines, printheads or varnish. |
| 6-Color Configuration Ready | The machine reserves space for 6-color setup, allowing flexible future upgrades for varnish, spot color or white ink printing. |
| Precise Registration for Double-Sided Printing | Simple operation for double-sided printing with convenient mechanical positioning. Registration error ≤0.2mm. High efficiency & stable quality, solves the alignment difficulty of manual lamination. |
| Direct Printing on Wide Range of Materials | Direct print on various boards for reliable & efficient industrial production. Ideal for customers with tight lead times and helps handle large orders with instant production capacity. |
| Stable Ink Circuit with Multiple Patented Industrial Inkjet Technologies | Multi-stage temperature control with 3 constant-temperature systems. Three heat sources keep ink temperature & viscosity consistent to minimize color difference. Large-capacity 3-stage constant-temperature ink cartridges prevent insufficient ink supply during long-run printing. |
| Non-Contact Printhead Cleaning for Longer Service Life | Negative-pressure ink suction cleans nozzle surface. Reduces risk of physical damage to printheads and avoids foreign particles being sucked into nozzles. |
| Vivid & Accurate Colors with Lower Ink Consumption | Adopts industry-leading UV dedicated software. Printing precision increased by 30%, while UV ink consumption reduced by 40% compared with conventional printers. |
 |
 |
|
||
| Material Options | Full-scenario Application | Highlights & Advantages | ||
| ●KT Board：Lightweight, low cost & easy to cut. Ideal for one-off photo backdrops for short-term events. ●PVC Foam Board：Rigid, waterproof, deformation-resistant & reusable, perfect for annual events and long-term mall decoration. ●Fabrication Capabilities：Multi-layer assembly, curved grooving, hollow carving, embossed relief and integrated light slot fabrication. |
●Festivals：Spring Festival, Dragon Boat Festival, Mid-Autumn Festival, National Day, Christmas, 520 / Qixi Festival ●Events：Birthday parties, baby showers, wedding backdrop, team building & gatherings ●Commercial：Store opening, mall market, exhibition booth, annual meeting & new product launch |
●Rich 3D fabrication for stunning dimensional visuals ●Flexible material options for different usage durations ●Modular split packaging, easy self-assembly ●Avoid flat printed look, heavy truss and expensive acrylic signs |
 |
 |
 |
 |
